Table 4-1. 200A Parts List
Item Description Part No.
Per
Unit
1
DIFFERENTIAL PRESSURE UNIT (DPU)
(NOT SHOWN)
200A USES 199 DPU
SEE DPU
MANUAL
1
2*
SCREW, BEZEL 0181-0007C 3
3
BEZEL (PART OF ITEM #24) 0277-0029C 1
4*
LENS, COVER (PART OF ITEM #24) 0181-0038C 1
5*
GASKET, BEZEL (PART OF ITEM #24) 0277-0026C 1
6*
POINTER ASSEMBLY: 1
WHITE 0288-0030B
BLACK 0288-0031B
7*
SCREW, SCALE PLATE, 4-40 x 3/16, SST, SLTD.
FILH.
0114-0023J 4
8**
SCALE PLATE 1
WHITE ON BLACK BACKGROUND 0200-0051C
BLACK ON WHITE BACKGROUND 0200-1014C
9
STOP, SNUBBER 0226-0028C 2
10*
LINK ASSEMBLY 0288-0036B 1
11
DRIVE ARM ASSEMBLY 0200-0015B 1
12
SCREW, 4-40 x 1/4, SST, RDH. 0111-0034J 2
13
WASHER, SPLIT LOCK, #4, SST 0003-0062K 2
14
WASHER, FLAT, #4, SST 0003-0096K 3
15
SCREW, 4-40 X 3/16, SST, SLTD, BDGH. 0117-0012J 1
16
BAR, STOP, OVERRANGE 0288-0028C 1
17
MOVEMENT ASSEMBLY 0288-0035B 1
18*
SCREW, 1/4-20 X 1/2, STL. CD. PL., SKT. FLH. 0240-0009J 4
19
CASE 0200-0052C 1
20
SCREW, 1/4-20 X 1, STL. CD. PL., SLTD., SSCR 0340-0003J 4
21
NUT, 1/4-20, HEX, STL. CD. PL. 0500-0010J 4
22
PLATE, FLUSH MOUNTING ADAPTER (ITEMS 20
AND 21 USED WITH ITEM 22)(NOT SHOWN)
0200-0014C 1
23
STUD, BEZEL, RETAINING, DRIV-LOK 0004-0005K 1
24
BEZEL ASSEMBLY 0277-0018B 1
25
CALIBRATION KIT (NOT SHOWN) 0288-1032B 1
Notes: * Indicates recommended spare part; ** SCALE PLATE INDENTIFICATION:
If the scale plate shows an SCR number, this will identify it. Otherwise, provide the
following information:
1. Square Root or Linear Graduations
2. Scale (e.g., 0-100, 25-0-100, etc.)
3. Number of Graduations (linear scales only)
4. Data (e.g., PSI (bar), inches of water column (meter), etc.)
5. Standard plates have black background
When ordering parts, specify serial number of instrument.
