Table 4-2. 227A/227C Parts List
Item Description Part No.
Per
Unit
1
CASE, INDICATOR 0227-0014C 1
2
BEZEL (PART OF ITEM #21) 0277-0029C 1
3*
LENS, COVER (PART OF ITEM #21) 0181-0038C 1
4*
GASKET (PART OF ITEM #21) 0277-0026C 1
5**
SCALE PLATE 1
WHITE ON BLACK BACKGROUND 0227-0013C
BLACK ON WHITE BACKGROUND 0227-1003C
6*
POINTER ASSEMBLY: 1
WHITE 0288-0030B
BLACK 0288-0031B
7
MOVEMENT ASSEMBLY 0288-0035B 1
8
DRIVE ARM ASSEMBLY 0226-0023B 1
9
LINK ASSEMBLY 0226-0020B 1
10
STOP BRACKET 0288-0028C 1
11*
BEZEL SCREWS, SST 0181-0007C 3
12
SNUBBER 0226-0028C 2
13
SCREW, SL FIL. HD. 4-40 X 3/16, SST 0114-0023J 4
14*
SCREW, BD. HD., 4-40 X 3/16, SST 0117-0012J 1
15*
WASHER, SPLIT LOCK, #4, SST 0003-0062K 2
16
SCREW, FLAT HD., #10 X 1/2 0240-0019J 6
17
SCREW, SLOTTED SET, 1/4-20 X 1 0340-0003J 4
18
NUT 0500-0010J 4
19
SCREW, RD. HD., 4-40 X 1/4, SST 0111-0034J 2
20
WASHER, FLAT, #4, SST 0003-0096K 1
21
BEZEL ASSEMBLY (ITEMS 2, 3, & 4) 0277-0018B 1
22
DIFFERENTIAL PRESSURE UNIT (DPU)
(NOT SHOWN)
227A USES 224 DPU
227C USES 224C DPU
SEE DPU
MANUAL
1
23
CALIBRATION KIT (NOT SHOWN) 0288-1032B 1
Notes: * Indicates recommended spare part; ** SCALE PLATE INDENTIFICATION:
If the scale plate shows an SCR number, this will identify it. Otherwise, provide the
following information:
1. Square Root or Linear Graduations
2. Scale (e.g., 0-100, 25-0-100, etc.)
3. Number of Graduations (linear scales only)
4. Data (e.g., PSI (bar), inches of water column (meter), etc.)
5. Standard plates have black background
When ordering parts, specify serial number of instrument.
