Bartscher Mini Plus - Operational Elements; Technical Specification

- 27 -
4.2 Operational elements
1
Temperature controller for upper heater
2
Upper heater operation indicator (orange)
3
Temperature controller for lower heater
4
Lower heater operation indicator (orange)
5
ON / OFF switch with integrated mains
indicator (green)
6
Baking chamber illumination switch
4.3 Technical specification
Name “Mini Plus” pizza oven
Art. no.:
203530
Realization:
 Stainless steel;
 Baking chamber with bottom from high
temperature-resistant stone, for 1 pizza Ø 35 cm;
 Independent adjustment of upper and lower
heaters;
 Internal illumination
Temperature range: 0 °C to 400 °C
Power supply: 2.0 kW / 230 V 50 Hz
Dimensions: W 575 x D 525 x H 270 mm
Baking chamber dimensions: W 410 x D 370 x H 90 mm
Weight: 24.15 kg
1
2
3
5
4
6
