Base Camp F235744 - Warranty

WARRANTY
This appliance is covered against faulty workmanship and materials for a period of 12 months from the date of
original purchase. The following items are not covered by warranty:
• Blockedjetnipples-Eachoftheseitemsareaserviceablepartandarereadilyavailablefromyourspecialist
outdoor retailer.
PART NO. SIZE BURNER PERFORMANCE WEIGHT
F 235744 23.22 x 11.02” 10,000 / 10,000/6,400 BTU 12.35lb
PART NO. SIZE BURNER PERFORMANCE WEIGHT
F 235782 23.22 x 11.02” 10,000 / 10,000/6,400 BTU 12.35lb
Parts List & Technical Data
1
2
3
3
10
11
12
13
13
14
5
4
6
6
6
6
6
6
7
7
7
8
8
8
9
9
9
Spare Part List
1 35420 Trivet
2 35421 Medium burner
3 35401 Large burner
4 35422 Gasjetmediumburner
5 35402 Gasjetlargeburner
6 35423 “O” ring for spindle
7 35404 Spindle
8 35405 Lock nut
9 35406 Control knob
10 35407 “O” ring for gas connector
11 35408 Regulator
12 35424 Piezo ignition
13 35425 Electrode-mid-right
14 35426 Electrode-left
