4.Camera Charging
Charging Indication
5.Camera Installation
① Choose a location where you can get the ideal viewing angle.
It is suggested to mount the camera 7-10 feet (2-3 meters)
above the ground.
② Turn the knob of the mounting bracket counterclockwise
to loosen and remove it.
③ Drill holes with a 15/64-inch (6 mm) drill bit and insert
expansion bolts into the holes;
Expansion bolts are necessary for walls made of hard
materials such as concrete, brick, or stucco.
5V USB Charger
Option 1 Option 2
USB Port 1
03
Please fully charge both cameras before first use. It takes about 5 hours to charge each camera.
Up to 26 ft （8m）
7-10ft
（2-3m）
Camera
Field-of-View
Motion
Detection
Zone
Fully charged: Off
Charging Time 5 hours
Indicator Light
Charging : Flash blue
