AW00123409000 Physical Interface
Basler ace USB 3.0 85
Note: In order to avoid loosing an external trigger signal make sure its pulse width
will be long enough to provide sufficient time for the camera’s input circuit to react:
The minimum required pulse width will be longer for the
opto-isolated input line compared to a GPIO line and for a
trigger signal using the active low state for triggering compared to a trigger
signal using the active high state.
As a general rule of thumb, an external trigger pulse width of 100 µs should be
long enough for most cases.
