Basler BE1-50/51B-101 User Manual

9252000991 Rev N BE1-50/51B Introduction iii
REVISION HISTORY
The following information provides a historical summary of the changes made to this instruction manual
(9252000991). Revisions are listed in reverse chronological order.
Manual
Revision and Date Change
N, 03/08
• Updated front panel drawings to show new target reset button.
• Added GOST-R to Section 1.
• Moved content of Section 7, Manual Change Information, to manual
Introduction.
• Moved Characteristic Curve graphs from Section 1 to new
Appendix A.
• Moved content of Section 6, Maintenance, into Section 4,
Installation.
M, 11/00
• Updated drawings in Section 2 to reflect changes to the PC board.
• Updated the manual to reflect the change in switch call out from
SW8 to SW3.
• Added new functionality to the PICKUP LED. It is now the
ACTIVE/PICKUP LED and will be green when active and red when
picked up.
L, 12/99
• Changed all drawings to show the newly designed front cover.
• Changed all references to the current for testing the targets to an ac
only type of current.
K, 02/99
• Page 2-2: added description to Locator K for 100 series relays, unit
revision Q and previous.
• Deleted Figure 2-2 from Section 2 and added it to new Section 8.
• Page 3-2: added description to Auxiliary Output Contacts for 100
series relays, unit revision R and subsequent.
• Added new Section 8, Relay Differences.
J, 05/98
• Added Patent Number to Specifications and changed the manual
format to reflect current manual styles.
I, 07/97
• Added Model # BE1-50/51B-203 to Table 1-1.
• Corrected Tables 1-3 and 1-4, Figure Number.
• Changed “pickup setting” to “pickup” on pages 1-7, Time
Characteristics equation, page 1-9, Time Reset, and Figures 1-6
through 1-14.
• Added Oscillatory to Surge Withstand Capability on page 1-11.
• Corrected Figure 1-18 to reflect the correct Time Dial range: 0.5 to
9.9.
• Changed Table 7-1 to add ECA and date data.
H, 02/96
• Incorporated changed in series 200 relays that added five
characteristic curves and changed switch SW8-3 functionality.
• Changed Section 5, Testing, to incorporate setting all sections of
switch SW8.
G, 10/95
• Corrected minor typographical errors in Section 1 and 2.
• Corrected Table 2-1, locator item K, Function.
• Changed Figure 5-2 and all testing target current source references
from 0.2 ampere to 1.0 ampere.
• Changed Table 7-1 to add ECA and date data.
F, 02/95
• Changed all sections to reflect 200 series relay additions and relay
modifications that deleted P2 and P3 jumpers and added switch
SW8.
• Changed Specifications, TIME and ISNT PICKUP accuracy; Output
Circuits, and Isolation (Dielectric Test).
E, 09/94
• Corrected Figure 4-8.
