Basler BIP2 c Series User Manual

Installation Guide
24 Basler IP Fixed Box Cameras
Gnd
Alt. Camera
Power
RS-485 B-
RS-485 A+
DC Out
5
2
3
8
1
6
+12 to +24
VDC
+24
VDC
Max
Switch
Device
RS-485 Gnd
RS-485 A+
RS-485 B-
Camera
+5
VDC
+5
VDC
1 kΩ
+5
VDC
1 kΩ
I/O-2
(Set as an output)
(Set as an output)
I/O-1
4
I/O-0
+5
VDC
1 kΩ
(Set as an input)
7
I/O Schematic, Variant 1 (Input Port Connected to Ground (Pin 1) via Switch)
