Installation Guide
Basler IP Fixed Box Cameras 23
EnglishLanguageLanguageLanguageLanguageLanguageLanguageLanguage
Pin #: 5 Function: RS-485 A+
Description: A+ pin for a standard RS-485 connection.
Pin #: 7 Function: RS-485 B-
Description: B- pin for a standard RE-485 connection.
By default, the I/O-0 port is set as an output with its
function set to user settable and the I/O-1 and I/O-2 ports
are set as inputs with their function set to monitor. The
explanations in Table 1 and the schematic on page 24
assume that you have changed the port settings.
Table 1: Terminal Connector Pin Assignments
