3.4.3. Parts of the controls for BATEC QUAD HYBRID
1
2
3
4
5
1. BATEC QUAD GRIPS
2. BATEC SHIFT LEVER
3. Back pedal brake
4. Display panel
5. BATEC MAGIC LEVER
