14 Attach the female connect with lter screen & black washer to your
water source.
15 Pick up the blue outlet hose (H.) This hose has a female connect with
a black washer on one side and a male connect for the spray nozzle
on the other.
16 With your hand, screw the female connect with black washer onto
the male connect (located at the bottom front on the unit) until tight.
17 Pick up the spray nozzle with washer installed (J.) and with your
hand, screw the nozzle onto the male connect on the blue outlet
hose (H.) until tight.
Make sure that all the ttings you just put into
place are water tight.
18 Pick up the bag containing the metering tip kit (E.) and open it.
19 Chose the 4 metering tips you wish to use.
We allow you to use the shampoos/conditioners of your
choosing with The Bathmaster. However, dilution ratios range
anywhere from Ready To Use all the way up to 85 to 1.
Please refer to Metering Tips Made Easy on page 9 of this
instructional booklet to assist you in choosing the right
metering tips.
20 After deciding what metering tips you want to use, press each rmly
into the black hose barb ttings on the left side of the unit. These are
labeled 1, 2, 3 and 4.
21 If you are having trouble getting the metering tips into the black
hose barb ttings, gently tap the metering tip(s) with a SMALL
hammer to get them in.
22 Pick up the cover of the unit and place it back on the unit until the
two quick release buttons snap back into place
23 Grab the brass round nut which you removed earlier and turn
clockwise until tight.
6
