Quick Release fittings for Seat and Handlebar heights
With the locking lever in the loose position, tighten the nut until
finger tight. The final tightening is done by moving the lever to the
locked position. To undo move the lever to the loose position to
enable height adjustment. Take care not to exceed the limit marked
on each post.
Loose Locked
Folding the Bicycle
1. FOLD PEDALS
Fold pedals by squeezing
in as per photo, and turning
through 90 degrees.
Turn the pedals to a
suitable position so they
are not trapped when
folding the frame.
2. FOLD FRAME
Release centre frame lock as follows:-
