BatteryMINDer 483CEC1 - SIMPLIFIED OPERATING INSTRUCTIONS; Basic Setup and Connection

BatteryMINDer
®
Model 483CEC1
Rev. A-051216 Page 8 P/N 483CEC1-MNL
Detailed Specifications
Plastic enclosure material: UL-94V0 Noryl or PC or PC+ABS
Enclosure Dimension: Approx. 9.06 in. (230mm) (L) x 4.72 in.
(120 mm) (W) x 2.36 in. (60 mm) (H)
Weight: Approx. 2.86 lb. (1.3 Kg)
Operating temperature: -20°C/-4°F to 40°C/104°F
Storage temperature: -40°C/-40°F to 85°C/185°F
Operating Humidity range: 0 to 95% RH
SIMPLIFIED OPERATING INSTRUCTIONS
Read and thoroughly understand ALL SAFETY Instructions, pages
3 - 5 including Preparing to Charge, DC Connection Precautions, Unit
Location and Qualifying Your Battery Set BEFORE proceeding further.
1. Install Ring Terminal Assembly (RTA-2415) to the first and last battery
in the series connected 48-V grouping. Use a digital volt meter to
assist. Observe Polarity bands: Red = Positive, Black = Negative.
2. Ambient Temperature Sensor, ATS-1 comes already installed on the
Temperature Sensor input connector (4). Do not detach.
3. Plug AC power cord (6) into a 120 Vac electrical outlet.
4. Observe POWER GREEN steady.
5. Observe BATTERY SET CONNECTION GREEN/RED LED indicator
(3E):
If lit RED, reverse battery set connector attachments on battery set.
IF IN DOUBT REGARDING ANY OF THE ABOVE, REFER TO Detailed Operating
Instructions, page 15.
