BatteryMINDer 483CEC1 - BatteryMINDer 483 CEC1 Features; Unit Overview and Components

BatteryMINDer
®
Model 483CEC1
Rev. A-051216 Page 9 P/N 483CEC1-MNL
BatteryMINDer 483CEC1 Features
1
Battery Type Selector button
2
Battery Charge Stage Indicators: See Table on next page
3
LED Indicators: See Table on next page
4
Temperature Sensor input connector with ATS-1 Ambient Temperature
Sensor installed (included)
5
Output cord with quick connect plug
6
Ring Terminal cordset with quick connect plug (included)
7
Mounting tabs
8
EZC-01 EZ Connector with screws (included)
9
Input power cordset
5
7
4
6
9
Refer to enlarged view
of unit label with detailed
descriptions on Page 11
for Sections 1, 2 and 3
VDC 483CEC1 LABEL---P/N 701-100476-01-R
2
7
1
3
8
