Argo 2011 ver.02 8 2011
13. THERMIC RISKS
The following situations are considered dangerous for the operator:
1. touching the iron base when working,
2. emptying the boiler when under pressure,
3. leaving garments on the heated ironing board: they might be damaged or even
burnt.
• Do not iron garments directly on
persons.
• Do not leave hot iron on garments.
• After use, always put iron on its
iron rest.
14. INTERVENTIONS AND SMALL REPAIRS
The following procedures MUST be carried out ONLY when the boiler is cold
and the plug is disconnected from the mains.
1. replace the padding (fig. 1: table cover) every 320 hrs. of operation or maximum
every 3 months. N.B.: the padding can be washed.
2. replacement of the iron;
3. replacement of the coil: to be done when boiler is turned off and is cold (fig.1 :
solenoid valve);
4. replacement of the steam hose: to be done when iron and boiler are turned off and
are cold (fig. 2),
5. cleaning of the water inlet filter (fig. 4) and cleaning of the foot valve filter (ARGO
with water tank – fig. 1).
15. CLEANING OF WATER FILTER
The cleaning of the filter is to be done whenever the warning is displayed. If the water is full
of impurities, cleaning should be done more often.
To clean the water filter:
1. turn off the main water supply tap;
2. open the front panel
3. unscrew the filter plug by using a wrench as shown
in fig. 4;
4. take out the filter;
5. by using running water, clean the filter in order to
eliminate all impurities;
6. re-assemble the filter, fix with the wrench and turn
on the main water supply tap, checking at the same
time if there are any leakages.
7. close the front panel
(To reset warning, see chapter 8)
ATTENTION:
THERMIC DANGER
INCANDESCENT
IRON BASE
Fig. 4
