Bauer Compressors P1 User Manual

Purification Systems
Page 39 3rd Edition, Rev 0 Chg 6
4.6.9 P10S II Purification System
Item Qty Part No. Description Notes
1 1 079416 Oil and Water Separator See Figure 4-23
2 1 011430 Condensate Drain Valve
3 2 VAL-0007 Check Valves
4 2 080144 27” Dryer Chamber See Figure 4-28
5 1 080145 27” Securus
®
Chamber See Figure 4-30
6 1 VAL-0377 Bleed Valve
7 1 VAL-0053 Pressure Maintaining Valve
8 1 VAL-0169 Safety Valve
9 1 MNR-0042 Securus II
©
Monitor
Figure 4-16 P10S II Purification System
OUT
IN
1
2
3
4
5
6
3
7
8
9
