Page 14 For technical questions, please call 1-888-866-5797. 57287
SAFETY OPERATION MAINTENANCESETUP
Parts List and Diagram
PLEASE READ THE FOLLOWING CAREFULLY
THE MANUFACTURER AND/OR DISTRIBUTOR HAS PROVIDED THE PARTS LIST AND ASSEMBLY DIAGRAM
IN THIS MANUAL AS A REFERENCE TOOL ONLY. NEITHER THE MANUFACTURER OR DISTRIBUTOR
MAKES ANY REPRESENTATION OR WARRANTY OF ANY KIND TO THE BUYER THAT HE OR SHE IS
QUALIFIED TO MAKE ANY REPAIRS TO THE PRODUCT, OR THAT HE OR SHE IS QUALIFIED TO REPLACE
ANY PARTS OF THE PRODUCT. IN FACT, THE MANUFACTURER AND/OR DISTRIBUTOR EXPRESSLY
STATES THAT ALL REPAIRS AND PARTS REPLACEMENTS SHOULD BE UNDERTAKEN BY CERTIFIED AND
LICENSED TECHNICIANS, AND NOT BY THE BUYER. THE BUYER ASSUMES ALL RISK AND LIABILITY
ARISING OUT OF HIS OR HER REPAIRS TO THE ORIGINAL PRODUCT OR REPLACEMENT PARTS
THERETO, OR ARISING OUT OF HIS OR HER INSTALLATION OF REPLACEMENT PARTS THERETO.
Parts List
Part Description Qty
1 Cover Screw w/ Spring & Flat Washer 6
2 Left Wheel Cover 1
3 Arbor Nut 1
4 Wheel Flange 4
5 Grinding Wheelø200*25*Φ15.88 1
6 Left Inner Wheel Guard 1
7 Eye Shield Locking Knob 2
8 Flat Washer 4
9 Eye Shield Support 1
10 Nut 2
11 Eye Shield 2
12 Hex Bolt 4
13 Flat Washer 4
14 Work Rest Locking Knob 2
15 Screw w/ Flat Washer 4
16 End Cap 2
17 Wave Washer 1
18 Bearing 2
19 Stator 1
20 Arbor 1
21 Right Inner Wheel Guard 1
22 Cord Bushing 1
23 Teeth Washer 1
24 Screw w/ Spring & Flat Washer 2
25 Power Cord With Plug 1
26 Cord Clip 1
27 Base 1
28 Locking Washer 1
29 Capacitor 1
Part Description Qty
30 Screw 4
31 Rubber Foot 4
32 Screw w/ Spring & Flat Washer 4
33 Grinding Wheelø200*25*Ø15.88 1
34 Arbor Nut 1
35 Right Wheel Cover 1
36 Switch Board 1
37 Switch 1
38 Screw w/ Spring & Flat Washer 2
39 Screw w/ Spring & Flat Washer 6
40 Nut 4
41 Right Work Rest 1
42 Base Plate 1
43 Eye Shield Plate 2
44 Screw 4
45 Hex Bolt w/ Spring & Flat Washer 4
46 Right Spark Guard 1
47 Left Spark Guard 1
48 Neck Screw 2
49 Cord Clip Plate 1
50 Screw 2
51 Hex Thin Nut 1
52 Flat Washer 1
53 LED Lamp 1
54 Lamp Transformer 1
55 Nut 2
56 Left Work Rest Support 1
57 Right Work Rest Support 1
58 Left Work Rest 1
Record Product’s Serial Number Here:
Note: If product has no serial number, record month and year of purchase instead.
Note: Some parts are listed and shown for illustration purposes only, and are not
available individually as replacement parts. Reference UPC 193175556561.
