Page 9For technical questions, please call 1-888-866-5797. 57287
SAFETYOPERATIONMAINTENANCE SETUP
11. Place the Grinding Wheel with the
Outer Flange onto the Arbor.
12. Thread the Nut onto the Arbor. Wrench
tighten only enough so that the Wheel
is securely held on the Arbor.
WARNING: To prevent serious injury, do
not overtighten Nut. Overtightening can
damage the wheel, causing wheel failure.
Correcting Wheel Balance
Confirm Wheel balance by spinning the Wheel by
hand and observing the Wheel distance from the
Tool Rest as it spins; variations in this distance
indicates the Wheel balance needs to be corrected:
1. Loosen Nut, and manually (if possible) adjust
the Wheel closer to the Arbor centerline;
hold in place while tightening the Nut.
2. Use a Wheel Dresser to remove the outermost
layer and / or high spots of the Grinding Wheel
to achieve Wheel balance. Follow the Wheel
Dresser Manufacturer’s instructions.
Note: If Wheel still vibrates excessively after the
Wheel has been dressed or adjusted to center
as described above, and Wheel does not exhibit
wobble from side to side at speed, Wheel is
likely out of balance and should be replaced.
Eliminating Wheel Wobble (Side to Side)
Note: Slight side to side wobble may exist as the
Wheel spins up or down from full speed, but this will
not affect normal operation. Follow the instructions
below to remove excessive side to side wobble:
1. Loosen Nut and rotate Outer Flange slightly.
Snug the Nut and rotate the Wheel by
hand to confirm wobble is eliminated.
2. If Wobble still exists, continue repeating step 1 in
slight increments in the same direction, making sure
Wheel is in the same orientation as it was in step 1.
3. If Wobble is still not eliminated, continue holding
Wheel in same orientation as it was in step
1, and rotate Inner Flange 90
o
. Repeat Steps
1-2. Continue this sequence of Inner and Outer
Flange movements until Wobble is eliminated.
Note: If necessary, a shim made of paper / card
stock may be placed between the Inner or Outer
Flange and Wheel. If excessive Wobble still
exists, consult ″Troubleshooting″ on page 13,
remembering these possible sources of imbalance:
• Wheel is not balanced or is out-of-round.
• Wheel Arbor bushing has excessive play.
• Wheel is of poor quality.
• Inner or Outer Flanges are warped.
