Page 10 For technical questions, please call 1-800-444-3353. 70757
SAFETY OPERATION MAINTENANCESETUP
Parts List and Diagram
Part Description Qty
1 Base Plate 1
2 Nut (I‑M10) 4
3 Washer (Ø10) 4
4 Caster 2
5 Nut (I‑M8) 12
6 Washer (Ø8) 6
7 Bolt (M6×20) 1
8 Foot 1
9 Washer (Ø6) 1
10 Nut (I‑M6) 15
11 Caster with Brake 2
12 Inlet Gasket 2
13 Screw (ST4.2×10") 4
14 Bolt (M6×20) 8
15 Bolt (M8×20) 4
16 Impeller 1
17 Impeller Washer 1
18 Bolt (M8x25) 1
19 Flange Fix Ring 1
20 Housing Seal 1
21 Inlet Housing 1
22 Inlet Gasket 1
23 Washer (Ø6) 8
24 Inlet 1
25 Washer (Ø8) 4
26 Nut (M8) 4
27 Screw (ST4.2×12.7") 5
28 Inlet 1
29 Inlet Cap 1
30 Dust Collection Bag 1
Part Description Qty
31 Bag Retainer 1
32 Dust Removal Plate 1
33 Bolt (M8x20) 10
34 Dust Scraper 3
35 Bolt (M6x12) 6
36 Stand 3
37 Bolt (M8×18) 6
38 Filter 1
39 Filter Clamp 1
40 Collector 1
41 Hose Clamp 2
42 Hose 1
43 Bolt (M8x25) 4
44 Motor 1
45 Motor Base 1
46 Flange Nut (M8) 4
47 Impeller Housing 1
48 Motor Seal 1
49 Outlet 1
50
Filter Assembly (with Scraper) 1
51
52
53
54
55 Nut (M8) 1
56 Handle 1
57 Nut (M10) 2
58 Washer 2
59 Washer 1
60 Cap Nut 1
Record Product’s Serial Number Here:
Note: If product has no serial number, record month and year of purchase instead.
Note: Some parts are listed and shown for illustration purposes only, and are not available individually as
replacement parts. Specify UPC 193175511560 when ordering parts.
