Manual for BAUER RAINSTAR A1, A2
22
Step 4:
By turning the helically grooved spindle, move the left guide bar to the value of
"0" towards the inner reel side
wall.
0
Thereby the spindle must be turned in the direction of winding (clockwise, see
sketch).
At this point, the winding carriage moves from the reversing point to the right
(direction A).
Step 5:
Mount the winding chain (1), the reel remains
unchanged with the inlet bend pointing down.
Tighten the winding chain (1).
WARNING!
1
