TP10243-3 PAGE 26
P28: Serial Output Type
This selection, in maintenance mode, shows selected
serial output type.
2.1.4 Diagnostic Parameters
Table 4. Machine Diagnostic Parameter List
P30: Input Port 1 Status
P31: Input Port 2 Status
P32: Input Port 3 Status
P33: Input Port 4 Status (Extension)
This selection shows the inputs status(see table4).
2.1.5 Future Features
Table 5. Future Features List
P34: Output Port 1 Status
P35: Output Port 2 (Extension)
This selection shows the outputs status (see table 4).
# Function Type Variable Displayed
P40 Last Knife Eye Time 1 Not used Not used Not used
P41 Last Knife Eye Time 2 Not used Not used Not used
P42 Last Knife Eye Time 3 Not used Not used Not used
P43 Strokes knife 1 Not used Not used Not used
P44 Strokes knife 2 Not used Not used Not used
P45 Strokes knife 3 Not used Not used Not used
P30 Status Input Port 1
P30.1 P30.2 P30.3 P30.4 P30.5 P30.6 P30.7 P30.8
Pile Motor Function Pile Down Pile Stop Pile Up Compress. Compress. Drive Start
Energized Control K1 Button Button Button Stop Button Start Button Relay K3
P31 Status Input Port 2
P31.1 P31.2 P31.3 P31.4 P31.5 P31.6 P31.7 P31.8
Pile Sensor Double Pile Sheet Start Sheet Stop Thermal Wrong Sheet Emerg.Stop
Sheet Fault Bottom Button Button Fault Fault Drive Stop
Button
P32 Status Input Port 3
P32.1 P32.2 P32.3 P32.4 P32.5 P32.6 P32.7 P32.8
Ergonomic Not used Not used Not used Not used Suction Delivery Photo eye
Pile Load Controller Count Input Suction
Eye Fail Wheel
P33 Status Input Port 4 (Extension Port)
P33.1 P33.2 P33.3 P33.4 P33.5 P33.6 P33.7 P33.8
Not used Not used Not used Not used Not used Not used Not used Not used
P34 Status Output Port 1
P34.1 N P34.2 P34.3 P34.4 P34.5 P34.6 P34.7 P34.8
Not used Not used Not used Not used Pile Down Pile up Release Compress
is active is active Drive Start Start (K4)
P35 Status Output Port 2 (Extension Port)
P35.1 P35.2 P35.3 P35.4 P35.5 P35.6 P35.7 P35.8
Not used Not used Not used Not used Not used Not used Not used Not used
