Using the hob top
The following symbols will appear on the control panel, next to each
control knob:
Black circle: gas off
Large flame: maximum setting
Small flame: minimum setting
o The minimum setting is at the end of the clockwise rotation of
the control knob.
o All operation positions must be selected between the maximum
and minimum positions.
o Never select a knob position between the maximum and off
position.
Automatic ignition with flame failure safety device
To ignite a burner:
o Press in the control knob of the
burner that you wish to light and
turn it clockwise to the maximum
position.
o If you keep the control knob
depressed, the automatic ignition
for the burner will operate.
o You should hold down the control knob for 20 seconds after the
flame on the burner has lit.
o After this 20 second interval, turn the control knob to your
required setting between the maximum and minimum setting
symbols.
