Electrical connection
YOUR HOB IS INTENDED FOR FITTED AND
PERMANENT INSTALLATION.
o Cable type: H05 RRF 3 core x 1.50 mm³ (Type RR-F <HAR>
marked).
o The mains cable is supplied with this product.
o Before connecting the appliance, make sure that the supply
voltage marked on the rating plate corresponds with your mains
supply voltage.
o We recommend that the appliance is connected by a qualified
electrician, who is a member of the N.I.C.E.I.C. and who will
comply with the I.E.E. and local regulations.
o WARNING: THIS APPLIANCE MUST BE EARTHED.
o The hob must be wired into a 13 A double pole switched fused
spur outlet, having 3 mm contact separation and placed in an
easily accessible position adjacent to the appliance. The spur
outlet must still be accessible even when your hob is located in
its housing.
o The wiring in the mains lead is coloured as follows:
Brown Live
Blue Neutral
Green and yellow Earth
o As the colours of the wires in the appliance’s mains lead may not
correspond with the coloured markings identifying the terminals
in your spur box, please proceed as follows:
The brown wire must be connected to the terminal marked “L”
(live), or coloured red.
The blue wire must be connected to the terminal marked “N”
(neutral), or coloured black.
The green and yellow wire must be connected to the terminal
marked “E” (earth), or by the earth symbol, or coloured green
and yellow.
