Installing the handle
o Remove the door gasket on the side you wish to install the
handle. You can see two designated holes for handle installation.
o Install the handle tightly as shown in the diagram above with the
two screws, lock washers and flat washers provided.
o Replace the door gasket.
Reversing the door of your wine cabinet
This appliance has the capability of the door opening from either the
left or right hand side.
Any parts that you remove from the appliance whilst
reversing the door, should be retained for later use.
o Open the glass door and remove the two
screws from Support Rod under the right
bottom corner of the glass door.
o Be careful to support the glass door with
both hands to prevent it dropping after
removing the screws.
o Pull down to remove the glass door and
place it on a padded surface to prevent
scratching it.
Support Rod
Screws
Support Rod
Right Lower Hinge
23
