Baumatic TEL06SS - Tel07 Ss

TEL07SS
PRODUCT DIMENSIONS
Height: 270 mm
Width: 600 mm
Depth: 306 mm (encased)
APERTURE DIMENSIONS
Width: 600 mm
Depth: 280 mm MIN
450 mm (extended)
Your cooker hood is fitted with:
o Electronic control operation
o 3 x speeds
o 2 x washable aluminium grease filters
o 2 x light
Extraction capacity: 750 m³/hr
Optional extras: 1 x Pair of ST1 Carbon filters for air
recirculation
All of the optional extras are available from the Baumatic
Spares Department.
9
