Accessories Installation
BUG 3/2/20 Basic Feed Unit 35
Baumüller Nürnberg GmbH 5.96064.02
Connection
Connect ballast resistor connector
to basic unit (refer to connection
1)
plan of basic unit)
Fan (24 V
DC
, 0.25 A, SELV)
Pre-warning Error
(Overrtemperature BUR) (SELV)
1)
When UL508C is considered: The resistor-units are only to
be used in connection with Baumüller-appliances of BUG and BUM61, 62 and 62T types.
Connections
Type Code
B U R - 6 2 2 - 0 4 - 2 - 0 0 0
0 8
1 6
BAUMOTRONIC
Resistor Unit
Type Series
Type
Resistor
Rated power 2 kW
Version
