Installation
50 Mono Power Unit BUM 62, 63, 64
5.94005.12 Baumüller Nürnberg GmbH
y 3-phase line reactors for 400 V supply voltage, T
A
= 55°C max.,U
k
= 4 % / 4.8 %,
U
N
= 400 V, 50/60 Hz, with flat termination IP 00
y 3-phase line reactors for 500 V supply voltage, T
A
= 55°C max., IP 00
U
k
= 4 % / 4.8 %, U
N
420 ... 500 V, 50/60 Hz, with flat termination IP 00
y EMC package
on requirement available:
- EMC filter
- shielded cable
- connection parts
Line
reactor
DR3-40-4l
Type
DC
current
A
a
mm
b
mm
c
mm
d
mm
e
mm
f x g
mm
Flat
termination
∅
mm x mm
Weight
kg
Losses
W
Part
no.
1900 ..
- 0 200 200 310 170 255 280 106 11 x 18 40 x 4 ∅ 14 28,0 160 -7474
- 0 400 400 310 220 260 280 131 11 x 18 40 x 4 ∅ 14 45,0 180 -7476
Line
reactor
DR3-40-4l
Type
DC
current
A
a
mm
b
mm
c
mm
d
mm
e
mm
f x g
mm
Flat
termination
∅
mm x mm
Weight
kg
Losses
W
Part
no.
1900 ..
- 0 200 200 270 170 230 200 102 10 x 18 30 x 4 ∅ 11 27,5 160 -7487
- 0 400 400 360 230 315 300 150 9 x 14 40 x 5 ∅ 14 73,0 225 -7489
