Installation and Service Manual
Gas Fired Wall Mounted Condensing Boiler
en
United Kingdom
These instructions include the Benchmark Commissioning Checklist and should be left with the
user for safe keeping. They must be read in conjunction with the Flue Installation Guide.
EcoBlue Heat
12 - 15 - 18 - 21 - 24

Table of Contents

Questions and Answers

  • H
    Heather WigginsAug 17, 2025
    Why is my Baxi Boiler flashing 1 red light indicating a sensor error?
    • A
      Allison BrooksAug 17, 2025
      If your Baxi Boiler displays 1 red flash, it indicates a sensor error. This could be due to a bad connection to the flow or return temperature sensor, a fault with the temperature sensors, low or no flow through the boiler, or reverse flow through the boiler. To address this: * Check the connections to the temperature sensors/PCB and the condition of the wiring loom. * Check the resistance of the temperature sensors. * Check the pump operation and system circulation.
  • J
    Judith AguilarAug 20, 2025
    What to do if my Baxi EcoBlue Heat 12 Boiler shows 3 red flashes for an ignition fault?
    • A
      Audrey RobinsonAug 20, 2025
      If your Baxi Boiler displays 3 red flashes, indicating an ignition fault, several issues could be the cause. It might be due to no ignition, no flame detected after ignition, a false flame signal, or repeated flame loss. To address this, you should: * Verify the appliance is properly earthed. * Inspect the ignition electrode, cleaning or replacing it if needed. * Check the operation of the gas valve. * Ensure the flue is in good condition. * Verify the combustion and gas valve settings are correct. * Inspect the condensate drain for any blockages.
  • J
    Jason MooreAug 22, 2025
    Why is my Baxi Boiler flashing 2 red lights indicating high temperature protection?
    • N
      Nancy FernandezAug 22, 2025
      If your Baxi Boiler is showing 2 red flashes, it indicates high temperature protection activation. This can happen if the over-temperature thermostat on the heat exchanger has been activated, there's no water flow through the heat exchanger, there's a fault or bad connection with the over-temperature thermostat, the PCB is experiencing an over-temperature condition, or there's a flue fault. To resolve this: * Check the connections and operation of the O/T thermostat and air pressure switch (if fitted), as well as the PCB and the condition of the wiring loom. * Ensure the system pressure is correct and that the system is not air-locked. * Verify the pump is operating correctly and the system is circulating water. * Inspect the flue for any issues.
  • E
    Edward ChangAug 25, 2025
    How to troubleshoot a Baxi Boiler when it flashes 1 green light for temperature protection?
    • S
      Suzanne ReevesAug 26, 2025
      If your Baxi Boiler displays 1 green flash, it indicates a temperature protection issue. This may be due to exceeding the maximum flow temperature, a high flow temperature rise rate, or an excessive difference between the flow and return temperatures. To resolve this: * Check the system circulation and pump operation. * Check the demands for boiler operation (switched live operation). * Check the temperature setting. * Check the temperature sensors in the boiler.
  • A
    Aaron SerranoAug 28, 2025
    What to do if my Baxi Boiler is flashing 3 green lights indicating flame loss?
    • G
      Glenda WrightAug 28, 2025
      If your Baxi Boiler displays 3 green flashes, this indicates a flame loss. This means no flame was detected during operation. To troubleshoot: * Check that the gas supply is turned on and gas is available, especially if you are using a pre-payment meter. * Inspect the flue condition.
  • J
    Jacob RamirezAug 30, 2025
    What does it mean when my Baxi EcoBlue Heat 12 flashes 4 red lights indicating a fan fault?
    • B
      Brent WilliamsAug 30, 2025
      If your Baxi Boiler is showing 4 red flashes, it indicates a fan fault, which can be due to a fan calibration error or fan failure. If the fan is operating, check the flue installation and condition. If necessary, replace the control/fan assembly.
  • S
    sandra94Sep 1, 2025
    What does it mean when my Baxi EcoBlue Heat 12 Boiler flashes 4 green lights indicating a communication fault?
    • A
      andrewmartinSep 1, 2025
      If your Baxi Boiler displays 4 green flashes, it indicates a communication fault, which can be caused by a bad connection, a wiring fault, or an internal communication fault. To resolve this, check the wiring and connections between the boiler and the User Interaction Controller, as well as within the box. If necessary, replace the control/fan assembly.
  • D
    dstewartSep 4, 2025
    What does 6 red flashes on my Baxi EcoBlue Heat 12 Boiler mean?
    • S
      Stephanie CantrellSep 4, 2025
      If your Baxi Boiler displays 6 red flashes, it indicates a miscellaneous issue. This can be due to a bad connection or wiring fault internal or external to the boiler, a parameter error, or a communication error. To address this, check that all wiring connections are correctly made. Use a service tool or Recom software to check all parameter settings. If necessary, replace the PU and/or control/fan assembly.
  • C
    christopherdawsonSep 6, 2025
    What does it mean when my Baxi EcoBlue Heat 12 flashes 2 green lights for shutdown input?
    • K
      Kevin StephensSep 7, 2025
      If your Baxi Boiler displays 2 green flashes, it indicates a shutdown input. This is caused by open circuit BL terminals on the User Interaction Controller. If a condensate pump is wired to these terminals, check its operation. Also, check the wiring to the BL terminals, ensuring the link is present or the connections to the external device are correct.
  • J
    Jorge OconnellSep 9, 2025
    What does it mean when my Baxi EcoBlue Heat 12 Boiler flashes 5 red lights indicating a parameter fault?
    • A
      andrewfernandezSep 9, 2025
      If your Baxi Boiler displays 5 red flashes, it indicates a parameter fault, which can be due to a bad connection to the PU or a parameter error or faulty PU. Check the PCB and condition of wiring loom. Replace the PU and recommission.

Summary

Introduction

General Information

General installation, repair, and maintenance by competent persons.

Documentation and Symbols

Refers to other documents and explains safety symbols.

Liabilities and Homologations

Outlines responsibilities, certifications, and directives.

Safety

General Safety Instructions

General safety instructions and warnings for operating the boiler.

Recommendations for Safe Installation

Advice on safe installation, handling, and potential risks.

Technical Specifications

Technical Data and Parameters

Key technical data, dimensions, ratings, and efficiency.

Dimensions, Connections, and Diagrams

Illustrates dimensions, clearances, connections, and diagrams.

Description of the Product

General Description and Operating Principle

Overview of boiler features, operation, and key components.

Main Components and Control Panel

Identifies key components and describes the control panel.

Standard Delivery and Optional Extras

Lists package contents and optional accessories.

Before Installation

Installation Regulations and Requirements

Guidelines and requirements for boiler installation.

System Setup and Water Treatment

System setup: water treatment, controls, and hard water areas.

Sealed Systems and Location Choice

Sealed systems, location choice, and bathroom safety.

Condensate Drain and Flue Installation

Condensate drain installation and service clearances.

Unpacking and Making Connections

Unpacking, initial preparation, and making connections.

Installation

Flue and Air Supply Connections

Connecting flue, air supply, and gas supply.

Electrical Connections

Electrical connections and system controls wiring.

System Filling and Completion

System filling, bleeding, and final installation checks.

Commissioning

Pre-Commissioning Checks and General

Pre-commissioning checks, standards, and general guidelines.

Commissioning Procedures and Gas Settings

Commissioning procedures, gas settings, and combustion checks.

System Configuration and Final Instructions

System configuration, gas pressure checks, and final handover.

Operation

General Operation and User Controls

Boiler operation, user controls, and frost protection.

Start-up, Shutdown, and Frost Protection

Start-up, shutdown, and frost protection procedures.

Settings

Parameters

Notes on operating parameters and settings.

Maintenance

General Inspection and Routine Maintenance

Annual servicing, routine inspection, and general maintenance.

Specific Component Maintenance

Procedures for replacing specific components like sensors and electrodes.

Valve, Fan, PCB, and Gas Settings Maintenance

Maintenance for valves, fans, PCBs, and gas settings adjustment.

Troubleshooting

Error Codes and Lockout Conditions

Explains error codes, status signals, and lockout conditions.

Decommissioning

Decommissioning Procedure

Procedure for safe dismantling and removal of the boiler.

Spare Parts

General and Spare Parts List

General advice on parts and a list of spare parts.

Commissioning Checklist

Service Record

Customer Support and Warranty

Baxi EcoBlue Heat 12 Specifications

General IconGeneral
BrandBaxi
ModelEcoBlue Heat 12
CategoryBoiler
LanguageEnglish
