4.4 Temporary heating temperature setting
The temperature is set by turning the B button to the right to increase the value and to the left to reduce it and
B to confirm.
The temperature to be set, for the heating circuit, may be:
• Original setpoint temperature: if the control unit is installed in the boiler.
• Ambient temperature: if the control unit is attached to the wall.
5 FUNCTIONS ASSOCIATED WITH THE QUICK MENU KEY
Press the A key and turn B to scroll through the following functions:
• On/Off then B to change the status
• DHW forcing then B to force the DHW mode
• CC1 regime
• CC1 comfort setting then B to activate the function selected, B to modify the value and B
• DHW regime to confirm.
• DHW comfort setting
• On/Off
When this function is activated, the display shows the symbol and the operation of the boiler in DHW regime and
heating is deactivated (the anti-freeze protection function is activated). To start the boiler up again, repeat the
procedure described above.
• DHW forcing
This function is used to raise the hot water tank’s temperature, if there is one, until it reaches the programmed temperature,
independently of the hourly range programmed (the symbol is present on the display)
• CC1 regime
The boiler operating mode can be selected from this menu, as indicated in chapter 4.
• CC1 comfort setting
Select this menu to modify the comfort ambient temperature value.
• DHW regime
Select this menu to activate (On) or deactivate (Off) the DHW production. The «Eco» function is not used for this boiler
model.
• DHW comfort setting
Select this menu to modify the maximum DHW temperature value.
When the DHW production is deactivated, the symbol disappears from the display.
