ESFRENG
User’s Guide BAT model
32
PARAMETERS TABLE
FUNCTION DESCRIPTION
F1 UNT
Sets the which units want to use: g / ct / lb / oz / d / gn / ozt / dwt / mm / tl.T / tl.c / tl.t / t use to
switch, use
key to sure.
F2 EL
Set the backlight to be on, automatic or off.
EL on: Backlight always on
EL Au: Backlight automatically turn on
EL off: Backlight allways off
Use
to switch, use key to sure.
F3 PRT
P cont, continuous sending.
P auto, when the weight is stable sends the data.
P prt, printer. Press
, now you can select the speed of transmission (600, 1200, 2400, 4800 or
9600 bps), press
to change speed and to save the wished speed. Now it selects the
printer (LP-50 or TP), press
to change printer and to save.
TECH
Pin
Enter the programming and calibration menus by entering the correct password (
)
and press
key to enter.
P1 LIN
Linear calibration.
Press
. Display will show PIN again. Press keys , , y to enter.
Display will show UNLOAD. Take off all the weight of the tray. Display will show the first request of
weight for the calibration. Place this weight on the tray, when the balance is stable ignites the stability
indicator and accepts this weight automatically.
After the first calibration of weight, display will show the following calibration weight. Place this weight
on the tray, when the balance is stable ignites the stability indicator and accepts this weight automa-
tically.
After the second calibration of weight, display will show the following calibration weight. Place this
weight on the tray, when the balance is stable ignites the stability indicator and accepts this weight
automatically.
The scale will begin to count backwards until reaching zero after it has accepted the last weight. During
the count down, you must retire all the weight of the platform.
The scale becames in normal weighing mode.
P2 CAL
After entering in the calibration mode, display will show UNLOAD. Take off all the weight of the tray.
When the scale is stable, it will fix initial zero point automatically. Then display will show LOAD. Place
the weight for the calibration on the scale.
Minimum calibration weights:
BAT300, 50g.
BAT600, 100g.
BAT1500, 300 g.
BAT3000, 500 g.
Place this weight on the tray, when the balance is stable ignites the stability indicator and accepts this
weight automatically.
The scale will begin to count backwards until reaching zero after it has accepted the weight. During the
count down, you must retire all the weight of the platform.
The scale becames in normal weighing mode.
P5 GRA
Gravity.
It appears the value of gravity, to change this value use the keys:
, places the value to 0.
, increases the value of the active digit.
, changes the active digit at right.
, changes the active digit at left.
Press
to save.
