0881537 IC TDA1308 SOP PCS 1 U702
0680013 SCHOTTKY DIODE 1N5819 PCS 1 VD701
0390057 MAGNETIC BEADS INDUCTOR RH354708 PCS 12 L701~L706,L707~L712
0410011 CHOKE COIL VERTICAL 10UH 2A 5mm PCS 1 L717
2100010 CONNECTION CORDS Φ0.6 SHAPED 5mm PCS 2 L714,L716
0410133
VERTICAL SCREEN-SHIELDED
FILTERING INDUCTOR
22UH 2A 5mm PCS 1 L715
0410118 CHOKE COIL JLB0904 PCS 1 L713
1090045
ELECTRO-OPTIC
TRANSFORMER
TX179ATW PCS 1 JK705
1090024
ELECTRO-OPTIC
TRANSFORMER
TX179AT PCS 1 JK705
1870030 POWER SOCKET DC-005 PCS 1 JK701
1910127 TERMINAL SOCKET S-VIDEO GOLD-PLATED PCS 1 JK703
1910167 TERMINAL SOCKET AV2-8.4-6G-3 GOLD-PLATED PCS 1 JK704
1910143 TERMINAL SOCKET AV3-8.4-6G-2 GOLD-PLATED PCS 1 JK702
1980046 HEADPHONE SOCKET ST-301-030-100 PCS 4 JK707,JK708,JK709,JK710
1940003 SOCKET 4P 2.5mm PCS 1 XS702
2110393 LEAD 26# 25mm BLACK WITH Φ3.2 WELDI
N
PCS 1
OUTPUT BOARD TO DECODE
BOARD
1940120 CABLE SOCKET
13P 1.0mm DUAL LINE TOUCH
STRAIGHT DUAL LINE PLUG
PCS 1 XS701
1631626 PCB 7317-3 PCS 1
1. SUBSIDIARY BOARD 1
MATERIAL CODE MATERIAL NAME SPECIFICATIONS UNIT
Q
UANTIT
Y
LOCATION
0090106 SMD RESISTOR 1/16W 4.7Ω ±5% 0603 PCS 1 R4
2121214 FLAT CABLE 2P230 2.0 1PLUG PCS 1 XS03
2121212 FLAT CABLE 2P280 2.0 1PLUG PCS 1 XS05
1940027 SOCKET 2P 2.0mm PCS 1 XS04
1562692 PCB A317-0 LEFT PCS 1
0620040 RADIATION DIODE 3B 4SC WHITE WITH BLUE PCS 1 LED06
1. SUBSIDIARY BOARD 2
MATERIAL CODE MATERIAL NAME SPECIFICATIONS UNIT
Q
UANTIT
Y
LOCATION
0090106 SMD RESISTOR 1/16W 4.7Ω ±5% 0603 PCS 4 R1,R2,R5,R6
1562691 PCB A317-0 FRONT PCS 1
0620040 RADIATION DIODE 3B 4SC WHITE WITH BLUE PCS 4 LED01~LED04
2121213 FLAT CABLE 2P260 2.0 1PLUG PCS 1 XS01
1. SUBSIDIARY BOARD 3
MATERIAL CODE MATERIAL NAME SPECIFICATIONS UNIT
Q
UANTIT
Y
LOCATION
0090106 SMD RESISTOR 1/16W 4.7Ω ±5% 0603 PCS 1 R3
1940027 SOCKET 2P 2.0mm PCS 1 XS02
1562690 PCB A317-0 RIGHT PCS 1
0620040 RADIATION DIODE 3B 4SC WHITE WITH BLUE PCS 1 LED05
1. SUBWOOFER POWER AMPLIFIER BOARD
MATERIAL CODE MATERIAL NAME SPECIFICATIONS UNIT
Q
UANTIT
Y
LOCATION
0000648 CARBON FILM RESISTOR 1/2W 4.7Ω±5% SHAPED 12.5 PCS 4 R108, R109, R130, R131
0010242
METAL
OXIDE
FILM
RESISTOR
1/2W560Ω±5% SHAPED 12.5 PCS 1 R114
0010243
METAL
OXIDE
FILM
RESISTOR
2W180Ω±5％SHAPED R 20×8
PCS 1 R121
0200219 CERAMIC RESISTOR CT7 400V 103 ±20% 10mm PCS 1 C150
0210030 TERYLENE CAPACITOR 100V 104 ±10% 7mm PCS 4 C122, C123, C145, C146
0210031 TERYLENE CAPACITOR 100V 224 ±10% 8mm PCS 2 C100, C101
0260041 CD CD11 25V220U±20%8×12 3.5 PCS 1 C149
0260134 CD CD11 25V4700U±20%16×35 7.5 PCS 2 C106, C107
570020 DIODE 1N5404 PCS 4 VD100, VD101, VD102, VD103
0881102 IC TDA7265 Multiwatt11 PCS 2 N101, N102
1940002 SOCKET 3P 2.5mm PCS 1 XS101
1940040 SOCKET 3P 3.96mm PCS 1 XS100
1940074 SOCKET 2P 7.92mm PCS 3 XS106, XS107, XS108
2110380 LEAD
22# 75mm BLACK WITH WELDING
PIECE HOLE φ4.2
PCS 1 WELD TO REAR SIDE OF XP111
2121318 FLAT CABLE 4P290 2.5 1PLUG WITH NEEDLE PCS 1 XP104
2121319 FLAT CABLE 4P215 2.5 2PLUG PCS 1 XP103
2150150 FLAT CABLE
7P220 2.5 2PLUG 4P SCREEN-
SHIELDED WITH NEEDLE THE
SAME DIRECTION
PCS 1 XP102
