BBK DK1000S - 10 Spare Parts List

DK1000S MATERIAL LIST
1. MAIN PANEL
MATERIAL CODE MATERIAL NAME SPECIFICATIONS UNIT
Q
UANTIT
Y
LOCATION
1200520 LCD SCREEN XKS3787-SP BLUE PCS 1 U401
0620105 LED GROUND LIGHT SOURCE QB03002-09C PCS 1 LED402
3026977 LCD BRACKET DL317 ORIGINAL COLOR PCS 1
4000413 TAPPING SCREW BB 2×5 H NICKEL PCS 2
2PCS FOR LED BRACKET AND
MAIN PANEL
5446163 PCB SEMI-FINISHED PRODUCT 4317-2 DK1000S (WITHOUT LED) PCS 1
1. MAIN PANEL WITHOUT LED
MATERIAL CODE MATERIAL NAME SPECIFICATIONS UNIT
Q
UANTIT
Y
LOCATION
0000181 CARBON FILM RESISTOR 1/4W220Ω±5% PCS 2 R402,R419
0000167 CARBON FILM RESISTOR 1/4W33Ω±5% PCS 1 R405
0000195 CARBON FILM RESISTOR 1/4W1K±5% PCS 4 R401,R415,R421,R423
0000175 CARBON FILM RESISTOR 1/4W100Ω±5% PCS 1 R407
0000163 CARBON FILM RESISTOR 1/4W10Ω±5% PCS 3 R413 ,R420,R422
0000233 CARBON FILM RESISTOR 1/4W62K±5% PCS 1 R404
0000268 CARBON FILM RESISTOR 1/4W2.2Ω±5% SHAPED 10 PCS 2 R408,R409
0570006 DIODE 1N4148 PCS 1 VD401
0260008 CD CD11C 10V47U±20%4×7 1.5 PCS 3 TC401~TC403
0620054
DUAL-COLOR RADIATION
DIODE
3RB9HW-A COMMON SHADE RED
AND BLUE
PCS 1 LED401
1340064
LIGHT TOUCH RESTORE
SWITCH
KFC-A06-2WB L3.8 PCS 6 K401~K406
0881683 IC PT6554LQ QFP PCS 1 U402
1940170 SOCKET 2P 2.0mm RIGHT-ANGLED PCS 1 XS402
0090019 SMD RESISTOR 1/16W 4.7K ±5% 0603 PCS 4 R416,R417,R418,R403
0310084 SMD CAPACITOR 50V 104 +80%-20% 0603 PCS 2 C402,C403
0200139 PORCELAIN CAPACITOR 50V 104 +80%-20% 5mm PCS 2 C401,C408
0200118 PORCELAIN CAPACITOR 50V 681 ±10% 5mm PCS 1 C404
0780050 TRIODE S8050D PCS 4 Q401,Q402,Q403,Q404
2121268 SOFT FLAT CABLE
7P60 2.0 2PLUG WITH L NEEDLE
REVERSE
PCS 1
2360016 RECEIVING HEAD HS0038B3V PCS 1 U403
2100004 CONNECTION CORDS Φ0.6 SHAPED 10mm PCS 1 R406
1631837 PCB 4317-2 PCS 1
1. AV BOARD
MATERIAL CODE MATERIAL NAME SPECIFICATIONS UNIT
Q
UANTIT
Y
LOCATION
0090181 SMD RESISTOR 1/16W 100Ω ±5% 0603 1 R702
0090001 SMD RESISTOR 1/16W 0Ω ±5% 0603 PCS 6 R725~R730
0090238 SMD RESISTOR 1/16W 68Ω ±5% 0603 PCS 1 R703
0090002 SMD RESISTOR 1/16W 2.2Ω ±5% 0603 PCS 1 R706
0090106 SMD RESISTOR 1/16W 4.7Ω ±5% 0603 PCS 2 R718,R719
0090008 SMD RESISTOR 1/16W 220Ω ±5% 0603 PCS 1 R701
0090018 SMD RESISTOR 1/16W 3.3K ±5% 0603 PCS 1 R712
0090224 SMD RESISTOR 1/16W 3.9K ±5% 0603 PCS 5 R710,R711,R713,R714,R715
0090023 SMD RESISTOR 1/16W 10K ±5% 0603 PCS 3 R707,R716,R717
0090014 SMD RESISTOR 1/16W 1K ±5% 0603 PCS 2 R720,R722
0090030 SMD RESISTOR 1/16W 56K ±5% 0603 PCS 2 R721,R723
0090481 PRECISION SMD RESISTOR 1/16W 30K±1% 0603 PCS 1 R709
0090304 PRECISION SMD RESISTOR 1/16W 10K±1% 0603 PCS 1 R708
0310047 SMD CAPACITOR 50V 101 ±5% NPO 0603 PCS 1 C720
0310066 SMD CAPACITOR 50V 102 ±10% 0603 PCS 6 C701~C706
0310083 SMD CAPACITOR 50V 20P ±5% 0603 PCS 6 C709,C712,C713,C714,C716,C717
0310072 SMD CAPACITOR 50V 103 ±10% 0603 PCS 1 C721
0310202 SMD CAPACITOR 50V 223 ±10% 0603 PCS 1 C723
0310207 SMD CAPACITOR 50V104 ±20% 0603 PCS 12
C710,C711,C715,C718,C719,C722,C
726,C727,C728,C729,C730,C731
0260039 CD CD11 25V47U±20%5×11 2 PCS 3 TC709,TC712,TC713
0260201 CD CD11C 16V100U±20%6×7 2.5 PCS 3 TC714,TC715,TC716
0260028 CD CD11 16V220U±20%6×12 2.5 PCS 1 TC708
0260029 CD CD11 16V470U±20%8×123.5 PCS 2 TC711,TC710
0260352 CD GS 10V1000U±20%8×14 3.5 PCS 1 TC707
0260237 CD CD11 10V1000U±20%8×14 3.5 PCS 1 TC707
0260252 CD GS 10V1000U±20%8×16 3.5 PCS 1 TC707
0260015 CD CD11 10V1000U±20%8×16 3.5 PCS 1 TC707
0881304 IC ZA3020 SO8 PCS 1 U701
