00000449 CARBON FILM RESISTOR 1/6W18K±5% PCS 1 R116
00000469 CARBON FILM RESISTOR 1/6W22K±5% PCS 2 R102, R103
00000489 CARBON FILM RESISTOR 1/6W27K±5% PCS 1 R114
00000499 CARBON FILM RESISTOR 1/6W30K±5% PCS 4 R106, R110, R112, R113
00000599 CARBON FILM RESISTOR 1/6W100K±5% PCS 1 R115
02003089 PORCELAIN CAPACITOR 50V 221±10% SHAPED 5mm PCS 1 C114
02101699 TERYLENE CAPACITOR
100V 273±10％ SHAPED 5mm
PCS 1 C118
02101489 TERYLENE CAPACITOR 100V 473 ±10% SHAPED 5mm PCS 2 C104, C105
02600059 CD CD11 50V1U±20%5×11 C5 PCS 2 C110, C113
02604379 CD CD11 16V10U±20%5×11C5 PCS 7
C100, C101, C102, C103,
C115,C116, C119
02600029 CD CD11 16V47U±20%5×11 C5 PCS 2 C106, C107
2100003 CONNECTION CORDS Φ0.6 SHAPED 7.5mm PCS 15
W1, W2, W3, W4, W5, W6, W8,
W9,W10, W13, W14, W15, W16,
W17,W18
2100004 CONNECTION CORDS Φ0.6 SHAPED 10mm PCS 2 W7, W12
2100006 CONNECTION CORDS Φ0.6 SHAPED 12.5mm PCS 1 W11
1. SUBWOOFER VOLUME CONTROL BOARD
MATERIAL CODE MATERIAL NAME SPECIFICATIONS UNIT
Q
UANTIT
Y
LOCATION
0000124 CARBON FILM RESISTOR 1/6W470Ω±5% SHAPED 7.5 PCS 1 R202
0000610 CARBON FILM RESISTOR 1/6W200Ω±5% SHAPED 7.5 PCS 1 R200
0160178 ROTATED POTENTIOMETER R1411GOA-H1B503FJ00-01 PCS 1 RP200
1563221 PCB 2500-1 PCS 1
1940002 SOCKET 3P 2.5mm PCS 1 XP101
1940006 SOCKET 6P 2.5mm PCS 1 XP105
2100003 CONNECTION CORDS Φ0.6 SHAPED 7.5mm PCS 2 W201,W202
2121486 FLAT CABLE 3P85 2.5 2PLUG WITH NEEDLE REVE
R
PCS 1
VOLUME CONTROL BOARD
XS109/STANDBY INDICATION
BOARD XP109
2121487 FLAT CABLE 2P95 2.5 2PLUG WITH NEEDLE REVE
R
PCS 1
VOLUME CONTROL BOARD
XS110/POWER INDICATION
BOARD XP110
5232411 PVC PIECE
33×29×0.5 SINGLE-SIDED WITH
GLUE IN REAR SIDE
PCS 1
SCREEN-SHIELDED MANTLE
AND PVC PIECE TO PREVENT
SHOR CIRCUIT
3540092 SCREEN-SHIELDED MANTLE SW500 PCS 1
WELD ON WELDING SURFACE
OF PCB
1. SUBWOOFER MAIN VOLUME INDICATION BOARD
MATERIAL CODE MATERIAL NAME SPECIFICATIONS UNIT
Q
UANTIT
Y
LOCATION
1563256 PCB A500-1 PCS 1
0620089 RADIATION DIODE
3B3SC COLORLESS WITH BLUE
BRIGHTNESS 2300MCD
PCS 1 VD400
1. DECODE BOARD
MATERIAL CODE MATERIAL NAME SPECIFICATIONS UNIT
Q
UANTIT
Y
LOCATION
0090001 SMD RESISTOR 1/16W 0Ω ±5% 0603 PCS 32
C2119,C2128,C2131,L210~L215,R2
01~R204,R212,R226,R228,R244,R25
1,R255,R257,R258,R268,R269,R272,
R282,R297,R298,R299,R303,R318,R
331,R2159
0090006 SMD RESISTOR 1/16W 75Ω ±5% 0603 PCS 7
R233,R261,R270,R273,R274,R276,R
280
0000707 SMD RESISTOR 1/4W5.6Ω±5% SHAPED 10 PCS 2 R326,R328
0090272 SMD RESISTOR 1/16W1Ω±5% 0603 PCS 6 R304~R307,R321,R340
0090003 SMD RESISTOR 1/16W 10Ω ±5% 0603 PCS 2 R301,R302
0090005 SMD RESISTOR 1/16W 33Ω ±5% 0603 PCS 16
R231,R232,R256,R291~R296,L202,
R263~R267,R2162
0090232 SMD RESISTOR 1/16W 150Ω ±5% 0603 PCS 1 R222
90009 SMD RESISTOR 1/16W 330Ω ±5% 0603 PCS 3 R344~R346
0090181 SMD RESISTOR 1/16W 100Ω ±5% 0603 PCS 4 R323,R324,R325,R327
0090013 SMD RESISTOR 1/16W 680Ω ±5% 0603 PCS 2 R259,R260
0090014 SMD RESISTOR 1/16W 1K ±5% 0603 PCS 21
R213,R215,R246,R247,R254,R278,R
2105,R2106,R2117~R2128,R279
0090016 SMD RESISTOR 1/16W 1.5K ±5% 0603 PCS 1 R243
0090249 SMD RESISTOR 1/16W 510Ω ±5% 0603 PCS 2 R214,R229
0090221 SMD RESISTOR 1/16W 120Ω ±5% 0603 PCS 1 R221
0090018 SMD RESISTOR 1/16W 3.3K ±5% 0603 PCS 1 R242
