4. Chassis Layout and Overall Wiring Diagrams
4.1 Chassis Layout
LCD19W57/LCD19W29EU:
LCD26W57:
LCD32W57:
No Description Part No Type/Model PCB/ Model
(1)
Main Board 116440 RSAG2.908.1295-1\ROH RSAG7.820.1269
(2)
Power Board 114538 RSAG2.908.1185-2\ROH RSAG7.820.1032
(3)
Keypad 117301 RSAG2.908.1088-1\ROH RSAG7.820.1101
(4)
IR & Led Board 116295 RSAG2.908.1260-2\ROH RSAG7.820.1337
No Description Part No
Type/Model PCB/ Model
(1)
Main Board 116132 RSAG2.908.1294\ROH RSAG7.820.1264
(2)
Power Board 1041467 JSI-190411B\ROH
(3)
Keypad 114552 RSAG2.908.1168-2\ROH RSAG7.820.1214
(4)
IR & Led Board 114175 RSAG2.908.1169 RSAG7.820.1213
No Description Part No
Type/Model PCB/ Model
(1)
Main Board 116134 RSAG2.908.1295\ROH RSAG7.820.1269
(2)
Power Board 115429 RSAG2.908.1251\ROH RSAG7.820.1235
(3)
Keypad 117301 RSAG2.908.1088-1\ROH RSAG7.820.1101
(4)
IR & Led Board 116295 RSAG2.908.1260-2\ROH RSAG7.820.1337
