BBK LCD19W57 - Explode View; Schematic Circuit Diagram

- 43 -
LCD TV Service Manual
8. Explode View
9 Schematic circuit diagram
Explode View：
LCD19W57
No. Part Name Qty. Code No. Remark
1 Pedestal 1 WG6.121.056
2 Screw 3 SJ2824-87 ST4×16C Black
3 Screw 4 SJ2824-87 ST4×16C Black
4 Screw 4 GB/T818-2000 M4×8 Black
5 Back cover 1 RSAG8.074.486
6 Bracket 2 RSAG8.038.1201
7 Screw 4 SJ2824-87 ST4×8F Black
8 Bracket 1 RSAG8.038.1351
9 Main Board Unit 1 RSAG2.908.1294-1
10 Screw 5 SJ2831-87 ST3×8 Zincification
11 Bracket unit 1 RSAG6.150.476
12 Screw 4 SJ2836-87 M3×6 Zincification
13 Power Board Unit 1 JSI-190411BROHJK
14 LCD Panel 1 HT190WG1-101JK
15 Front cover 1 RSAG8.074.506
16 Screw 4 GB/T819.1-2000 M3X6 Zincification
17 Key 1 RSAG8.335.0732
18 Key board unit 1 RSAG2.908.1168-2
19 Power Switch 1 SDDJE30300\JK
20 Lens led 1 RSAG8.640.062
21 IR Board Unit 1 RSAG2.908.1169
22 Screw 2 SJ2831-87 ST3×8C Zincification
23 Speaker 2 YDT37E-3W8R-F
24 Screw 4 SJ2838-87 ST4×16C.II Zincification
25 Screw 3 SJ2825-87 ST3×12C Black
