PRODUCT ASSEMBLY
3
4
Insert the cam bolts on the short table left/right legs into the part 8 short board. Insert four
part D cam locks into the table back, and attach the legs by locking the cam locks.
3
5
8
5
3
Screw eleven part A cam bolts into the part 3 short table left leg and part 5 short table right leg.
NOTE: Some of the embedded holes are covered with PVC, which can be directly screwed with
part A cam bolts.
x11
A
x4
D
BACK VIEW
