BCP SKY1829 - Outer Frame Assembly; Step 1: Assemble Outer Frame; Step 2: Assemble Seat Frame

1
2
PRODUCT ASSEMBLY
Please retain these instructions for future reference.
Assemble the outer frame. Slide on the part J canopy frame before connecting part A to part C.
Attach the Part E legs with the
knobs provided on the legs.
Place part 8 between the two part D seat frame curved pipes and secure with the part 1 bolt set.
Hook part 7 to part 8 as shown. Place a part L nut cap over the exposed nut.
Pg. 3
7
8
1
L
END RESULT
A
J
C
B
E
3
2
1
D
D
7
8
L
