BCP SKY5871 - Step 3: Assemble Outer Frame; Step 4: Connect Seat Frame Pipes

4
PRODUCT ASSEMBLY
Place part 8 between the two part D seat frame curved pipes and secure with the part 1 bolt
set. Hook part 7 to part 8 as shown. Place a part L nut cap over the exposed nut and insert two
part R end caps into the part D frame pipes.
RR
END RESULT
D
D
1
8
L
| 5
RIGHT
LEFT
3
Assemble the outer frame.
Attach the part E legs with the knobs provided
on the legs.
Insert two part Q end caps into the part A and
part C curved pipes.
Attach two part P leg caps to the part B leg.
A
B
E
E
C
O
3
P
2
P
Q
Q
7
L
L
