PRODUCT ASSEMBLY
14
Insert the hinge peg on the part 16 sink cupboard door into the opening on the part 9 counter panel.
Insert one part N hinge peg into the opening on the part 12 base, and secure to the part 16
cupboard door with two part D screws.
9
N
D
x2
16
