PRODUCT ASSEMBLY
15
Insert the hinge peg on the part 17 oven door into the opening on the part 9 counter panel.
Insert one part H hinge peg into the opening on the part 12 base, and secure to the part 17 oven
door with two part D screws.
H
D
x2
17
| 17
