BDCOM GP3600-16 GPON Hardware Installation Manual
- 2 -
1
P2
LED of power supply 2
When PWR2 supplies power, this LED
is on.
2
P1
LED of power supply 1
When PWR1 supplies power, this LED
is on.
3
SYS
LED of system’s running
If the indicator is always on, the system
is being started.
If the indicator flickers, the system
works normally.
4
ALM
System Alarm indicator
If the indicator is always off, the system
works normally;
If the indicator is on, the temperature of
the device is over high and need to
check.
5
G1~G8
Gigabit ACT/link indicator
If the indicator is always on, the link on
the port is normal.
If the indicator flickers, the data is
received or transmitted through the
port.
6
T1~T4
10GE ACT/link indicator
If the indicator is always on, the link on
the port is normal.
If the indicator flickers, the data is
received or transmitted through the
port.
7
P1~P16
16 PON port ACT/link
indicators
If the indicator is on, the device has
been connected;
If the indicator flickers, the data is
received or transmitted through the
port.
8
Console
Console port
Manages GPON access device locally.
9
MGMT
Management port
100M external management port.
Realizes the upgrade of the GPON
access device.
10
G1~G4
Gigabit TX port
Forwards the 1000M Ethernet electric
signals.
11
G1~G8
Gigabit SFP port
Forwards the 1000M Ethernet optical
signals
12
T1~T4
10GE optical port
Forwards the 10000M Ethernet optical
