The BDI Corridor 8172 Audio Tower is a stylish and functional cabinet designed to house audio equipment and media, offering both aesthetic appeal and practical features for organization and accessibility.

Function Description:

The Corridor 8172 Audio Tower serves as a dedicated storage solution for audio components, LPs, and other media. Its design, by Matthew Weatherly, emphasizes both form and function, making it suitable for modern living spaces. The cabinet features adjustable shelves to accommodate various equipment sizes and a thoughtful design for cable management. The door's reversible swing allows for flexible placement and user preference. Integrated levelers ensure stability on uneven floors, and the option to remove pre-installed wheels provides further customization for stationary use. The unit is designed for simple assembly, with clear instructions provided to guide users through the setup process.

Important Technical Specifications:

Model: Corridor 8172 Audio Tower
Dimensions (assembled): The manual provides an illustration of the assembled unit, which appears to be a tall, slender cabinet. Specific dimensions are not explicitly listed in the provided pages but can be inferred from the components and overall design as a vertical audio tower.
Materials: The cabinet features a glass top, metal legs, and a back panel. The construction includes high-quality European hinge hardware for the door. Wood and machine screws are used for assembly.
Hardware Components:
- Phillips Screwdriver (A)
- Hex Wrench (B1)
- Open Mouth Wrench (B2)
- Small Hex Wrench (B3)
- 1/4-20 x 10mm Machine Screws (D) (12 qty)
- Metal Legs (E & F) (1 of each)
- 1/4-20 x 63mm Machine Screw (M) (1 qty)
- Stretcher (N) (1 qty)
- Glass Top (G) (1 qty)
- Rubber Bumpers (H) (4 qty)
- Large Adjustable Shelves (I) (2 qty)
- Small Adjustable Shelf (J) (1 qty)
- Back Panel (K) (1 qty)
- LP Storage Bars (L) (3 qty)
Weight Capacity: Not explicitly stated, but the design suggests robust support for audio equipment.
Assembly: Engineered for simple assembly, requiring basic tools provided (Phillips screwdriver, hex wrenches, open mouth wrench). Power tools are not recommended.

Usage Features:

Adjustable Shelves: The cabinet includes two large adjustable shelves (I) and one small adjustable shelf (J). These shelves can be easily repositioned to accommodate various sizes of audio components, such as amplifiers, receivers, turntables, or media players. Shelf support pins can be removed and reinstalled at desired heights.
LP Record Storage: The Corridor 8172 is specifically designed with LP record storage in mind. It features three LP Storage Bars (L) that can be placed into designated holes in the bottom of the cabinet to organize records. When not in use, these bars can be stored in designated holes in the back of the cabinet.
Reversible Door Swing: The door can be configured to hinge on either the left or right side, providing flexibility for placement within a room and user convenience. This adjustment involves removing and reattaching hinge plates and adjusting door catches.
Door Alignment and Adjustments: The cabinet features high-quality European hinge hardware that allows for fine-tuning of door alignment. Users can adjust screws on the hinges to move the door left/right or in/out, ensuring a perfect fit and even spacing. Additionally, a set screw in the middle of the door's metal bars can be adjusted with a small hex wrench to straighten the door's depth, pushing it outward or inward.
Levelers: Integrated levelers in each metal leg can be adjusted using the open mouth wrench (B2). This feature allows users to stabilize the cabinet on uneven floors, preventing wobbling and ensuring a level surface for audio equipment. Turning the leveler clockwise extends it, while counter-clockwise retracts it.
Optional Wheel Removal: The pre-installed wheel assembly can be detached from the metal legs by removing the leveler and screw, allowing for a stationary setup if preferred. The leveler can then be reinstalled directly onto the metal legs.
Cable Management: Velcro straps are included with the back panel (K) to facilitate wire management, helping to keep cables tidy and organized behind the unit. The back panel itself is designed to be easily installed by inserting the top edge into an upper channel and then tipping the bottom edge into a lower channel.
Glass Top: A glass top (G) is provided, which is placed on top of the cabinet after rubber bumpers (H) are installed near the corners. This glass top adds a premium aesthetic and a durable surface.

Maintenance Features:

Glass Surface Care: The glass top (G) should be maintained using household glass cleaner and a paper towel or cloth.
Satin-Etched Glass Care: For satin-etched glass surfaces, a smooth-to-the-touch finish, regular cleaning with household glass cleaner and a paper towel or cloth is recommended. Minor scratches or scuffs can often be removed using a "Magic Eraser" (a melamine foam product). The Magic Eraser should be dampened and rubbed gently over the entire glass surface in broad, even strokes using moderate pressure. After cleaning, the surface should be wiped with a paper towel. Regular checks for results and repeat as necessary are advised. For deeper scratches, professional assistance may be required.
Wood Surface Care: Wood surfaces should be cleaned with a slightly damp (not saturated) cloth or paper towel. Do not use glass cleaner on wood. If moisture remains, dry the surface with another cloth. A gentle non-abrasive cleaner may be used, but ensure to wipe away all cleaner residue and dry the surface with a cloth. BDI's wood finishes feature natural hardwood solids and veneers, which are protected by a durable finish. Avoid direct sunlight to prevent discoloration.
Metal & Painted Surfaces Care: These surfaces should be cleaned with a slightly damp (not saturated) cloth or paper towel. If moisture remains, dry the surface with another cloth. A gentle non-abrasive cleaner may be used, but ensure to wipe away all cleaner residue and dry the surface with a cloth.
Warranty: BDI offers a three (3) year warranty from the date of purchase for its Home Theater Furniture, Office Furniture, Modular Systems, Tables, and other furniture pieces. This warranty covers defects in material or workmanship under normal use and applies to the original purchaser from BDI Authorized Resellers. Proper assembly, installation, use, and maintenance according to BDI's instructions are required for warranty coverage. Modifications to the product void the warranty.
Product Registration: Users are encouraged to register their new BDI product to receive important product updates, service information, and helpful hints. Registration also enters them into a drawing to win a BINK table.
Tip-Over Prevention: A crucial safety feature is the inclusion of a tip-over restraint. Users are warned to install this restraint, place the heaviest items in lower compartments, never allow children to climb or hang on drawers/doors/shelves, and never open more than one drawer at a time. This restraint reduces, but does not eliminate, the risk of tip-over injuries.

BDI Corridor 8172 - Page 16
