6 | BDIUSA.COM CORRIDOR 8172
Slide (E & F) Metal Legs into (N) Stretcher and
attach by using (B1) Hex Wrench and 4 (D) Screws.
Fully tighten all screws.
Removal of wheels (optional):
Detach Wheel Assembly from
(E & F) Metal Legs by removing
the Leveler and Screw.
Reinstall Leveler to
(E & F) Metal Legs.
PART/DESCRIPTION QTY
B1-HEX WRENCH 1
D-SCREW 4
E EF F
STEP 1. BUILD THE BASEASSEMBLY
For your convenience, wheel assembly is pre-installed. Wheels can be removed if desired.
E
N
F
D D
D
N
F
