NEVER LEAVE HEATER UNATTENDED WHILE BURNING OR
WHILE CONNECTED TO A POWER SOURCE
© 2020, BE Pressure Kerosene Forced Air Heater User’s Manual
Hot Air Outlet
Lower Shell
Upper Shell
Digital
Temperature
Display
Front Handle
Extension
Cord Wrap
Rear Handle
Fan Guard
Pressure
Gauge
Fuel
Gauge
Fuel Cap
Power Cord
Power/Reset Switch
Lamp
Side Cover
Thermostat Knob
Fuel Tank
Drain Bolt
3
Specications
Features
Model # HK045F HK070F HK125FW HK175FW HK215FW
Rating: kW 13 20.5 37 52 63
Fuel Consumption: L/Hr 1.32 2.00 3.60 5.07 6.17
Fuel Tank Capacity: Liters 19 19 38 49 49
Pump Pressure: PSI /BAR 3.0 / 0.21 3.7 / 0.26 4.5 / 0.31 7.5 / 0.52 8.0 / 0.55
Volts: AC/Hz
240VAC / 50Hz 240VAC / 50Hz 240VAC / 50Hz 240VAC / 50Hz 240VAC / 50Hz
Phase
Single Single Single Single Single
Specications subject to change without notice.
Hot Air Outlet
Upper Shell
Lower Shell
Fuel Tank
Fan Guard
Pressure Gauge
Fuel Gauge
Fuel Cap
Side Cover
Thermostat Knob
(HK070F only)
Lamp
Power Cord
Power/Reset Switch
Handle
Extension
Cord Wrap
Models: HK045F / HK070F
Models: HK125FW / HK175FW / HK215FW
Figure 1
Figure 2
