Beacon 800 - Specifications

Beacon 800 Gas Monitor Operator’s Manual Specifications • 2
Specifications
Table 1 lists specifications for the Beacon 800.
Table 1: Beacon 800 Specifications
Description Specification
Input Power 100 to 240 VAC or 24 VDC
Detector Head Input Type 2 or 3 wire 4-20mA transmitters
Construction (housing) Fiberglass/polyester with lexan window (NEMA 4X)
Dimensions 12.5 in. H x 11.0 in. W x 6.4 in. D
(31.8 cm H x 27.9 cm W x 16.3 cm D)
Weight 10.4 lbs. (without AC line cord)
Operating Temperature -4°F to 122°F (-20°C to 50°C)
Storage Temperature -4°F to 158°F (-20°C to 70°C)
Regulatory CSA, NRTL/C
Environmental Conditions • For indoor or outdoor locations (Type 4X)
• 2000 meter max altitude
• Maximum humidity: 80% relative
• Pollution Degree 2
• Installation Category II
User Controls • Reset switch
• Program buttons: ESCAPE, UP (YES), DOWN (NO), and ENTER)
Relays CSA Rated for 3 amps at 115 VAC resistive, Form C
Standard Accessory Operator’s manual (this document)
