Steps should be taken before flying
① Extend the transmitter antenna.
② Put the throttle stick of the transmitter at low position and then turn on the transmitter.
③ Put the hold key at on position. (This will prevent the main rotor from rotating abruptly
in case that you put the throttle stick at high position inadvertantly).
④ Connect the battery to the esc.
⑤ Wait until the ESC sets up itself with buzzing sound.
⑥ Move the elevator and ailron sticks of the transmitter and check up the swash movement.
⑦ If everything goes all right, turn the hold key off.
⑧ Start the main rotor by moving the throttle stick up slowly.
※ Refer to the transmitter manual for setting up hold key.
Data Sheet, 120˚ CCPM
① Swash type : 120˚
② Choose the heli appointment
③ Setting up servo reverse function
④ Setting up swash mixing
⑤ ATV (travel adjustment)
※ When setting up servo limits, please set ATV at 150 %.
Aileron Elevator Pitch
-60 60 60
Pitch
100
Trottle Aileron Elevator
Nor Nor Rev
Rudder
Nor
Pitch
Rec
100 100 150 100
Trottle Aileron Elevator Rudder
6
7
