Channel Setting
This device can control up to 12 x 20-channel scanners. The first 8 channels of each scanner can be controlled
through the 8 faders. The next 8 channels are controlled through the 8 faders and the PAGE selection button (10) on
page B.
If the scanner features more than 16 channels, set the channels as follows:
• Press the PROGRAM button (11) until the LEDs blink.
• Press the FINE (25) and the MODE (28) buttons simultaneously until the ASSIGN LED (20) turns on.
• Select your scanner by pressing the corresponding SCANNER button (1).
• Adjust the SPEED fader (23) to select the scanner channel (e.g. channel 9 or 10).
• Adjust the FADE TIME fader (24) to select the respective control channel of the controller (e.g. PAN (27A) or TILT
(27B) wheel).
• To set channel 19 and 20, press the PAGE selection button (10). The PAGE B indicator LED (9) will light. Repeat the
two previous steps.
Example: Set the SPEED fader (23) to channel 9 and the TIME fader (24) to X. This means the 9th channel of the
scanner will be controlled by the PAN wheel (27A).
FADE TIME Assignment
With this function you can determine whether the fade time should be assigned to the pan/tilt movement or to all DMX
channels. This is useful when the mirror or the moving head movement should be carried out slowly but the gobos
and colours should be changed quickly.
• Turn of the device.
• Simultaneously press and hold the MODE (28) and the TAP DISPLAY button (17).
• Turn on the device. Press the TAP / DISPLAY button (17) in order to switch between the two modes (ALL CH for all
channels and ONLY X/Y for pan/tilt movement only).
• Simultaneously press and hold the MODE (28) and TAP / DISPLAY button (17) to memorise your settings. All LEDs
on the panel will flash indicating the setting has been saved.
Operation
Manual
To select the manual mode, press the AUTO / DEL button (21) until the MANUAL LED (14) lights.
In manual mode you can call up the connected scanners manually and control them through the faders. Note that the
settings cannot be memorized. Select the desired scanner using the corresponding SCANNER button (1). Adjust the
desired function through the faders.
• Checking a BANK / SCENE
Select the desired bank using the BANK buttons (16 and 17). Select the desired scene using the SCENE buttons (3).
• Checking a CHASER
Select the desired chaser using the CHASER buttons (22). Press TAP / DELAY (17). The display will show the steps
in the chaser. Press the BANK buttons (16 and 17) to see each scene.
• The PAGE selection button (10)
Use this button to adjust the channel faders (4) from CH1 ~ 8 (page A LED is lit) to CH9 ~ 16 (page B LED is lit) or
both of them (both LEDs are lit).
• The DISPLAY button (17)
Use this button to switch the display from a DMX value (0 ~ 255) to a percentage (0 ~ 100%).
