DMX CHANNELS / DMX KANALEN / DMX-KANÄLE / CANALES DMX /
CANAUX DMX / KANAŁY DMX
10 channels
Channel
Function
Value
Description
1
Pan
000-255
Adjust Pan motor movement 540°
2
Tilt
000-255
Adjust Tilt movement 200°
3
Speed
000-255
Pan speed
4
Dimmer
000-255
Dimmer 0-100%
5 Strobe
000-005
Open
006-240
Strobe from slow to fast
241-249
Random strobe
250-255
Open
6 Colours
000-017
Open
018-035
Blue
036-053
Orange
054-071
Magenta
072-089
Cyan
090-107
Red
108-125
Lime
126-143
Pink
144-161
Yellow
162-199
Colour automatically skipped from fast to slow
200-227
Forwards rainbow effect from fast to slow
228-255
Backwards rainbow effect from slow to fast
7 Gobo
000-019
Open
020-039
Gobo 1
040-059
Gobo 2
060-079
Gobo 3
080-099
Gobo 4
100-119
Gobo 5
120-139
Gobo 6
140-159
Gobo 7
160-179
Forwards stepped rotation from fast to slow
180-199
Backwards stepped rotation from slow to fast
200-226
Forward lined rotation from fast to slow
227-255
Backwards lined rotation from slow to fast
8 Gobo rotation
000-019
Gobo rotation stop
020-099
Forwards gobo rotation from fast to slow
100-179
Backwards gobo rotation from slow to fast
180-255
Forwards backwards rotation from slow to fast
9 Prisma 3 facet
000-009
Prisma Out
010-127
Prisma In (static)
128-255
Prisma in (With rotation from slow to fast)
10 Control
000-019
No function
020-039
Auto 1
040-059
Auto 2
060-199
No function
200-219
Reset after 2 sec
220-255
No function
