Beamz illusion 2 - DMX Channel Configuration: 12 Channels (Part 1); 12 Channels DMX: Channels 1-10

DMX CHANNELS / DMX KANALEN / DMX-KANÄLE / CANALES DMX /
CANAUX DMX / KANAŁY DMX
12 Channels
Channel
Function
Value
Description
1
Pan
000-255
Pan 0-630°
2
Tilt
000-255
Tilt 0-210°
3
Speed
000-255
Pan/Tilt from fast to slow
4
Dimming
000-255
Led dimming
5
Strobe
000-015
Strobe off
016-095
Strobe slow – Fast 1Hz to 25Hz
096-175
Strobe slow – Fast 1Hz
176-255
Random strobe
6
Colour Wheel
000-030
Open
031-055
Red
056-080
Green
081-105
Blue
106-130
Yellow
131-155
Orange
156-180
Magenta
181-205
Light green
206-230
Purple
231-255
Cyan
7
Gobo wheel
000-021
Open
022-034
Gobo 1
035-047
Gobo 2
048-060
Gobo 3
061-073
Gobo 4
074-086
Gobo 5
087-099
Gobo 6
100-112
Gobo 7
113-125
Gobo 8
126-138
Gobo 9
139-151
Gobo 1 Shake from slow to fast
152-164
Gobo 2 Shake from slow to fast
165-177
Gobo 3 Shake from slow to fast
178-190
Gobo 4 Shake from slow to fast
191-203
Gobo 5 Shake from slow to fast
204-216
Gobo 6 Shake from slow to fast
217-229
Gobo 7 Shake from slow to fast
230-242
Gobo 8 Shake from slow to fast
243-255
Gobo 9 Shake from slow to fast
8
SMD ring strobe
000-029
SMD ring strobe off
030-225
Strobe on, Speed from slow to fast (Valid for Ch10 000-070 only)
226-255
SMD ring strobe off
9
SMD ring dimming
000-255
0-100%
10
SMD ring auto program
000-035
No function
036-040
Red
041-045
Green
046-050
Blue
051-055
Yellow
056-060
Magenta
061-065
Cyan
066-070
White
071-080
RGB fading
081-085
RED-chase
086-090
Green-chase
091-095
Blue-chase
096-100
R/G chase
101-105
R/B chase
106-110
G/B chase
111-115
R/G/B chase
116-120
Red ring zoom out
121-125
Green ring zoom out
126-130
Blue ring zoom out
