Beamz illusion 2 - DMX Channel Configuration: 12 & 23 Channels; 12 Channels DMX: Channels 10-12; 23 Channels DMX: Channels 1-9

Channel
Function
Value
Description
10
SMD ring auto program
131-135
R/G/B/W ring zoom out
136-140
Red ring zoom in
141-145
Green ring zoom in
146-150
Blue ring zoom in
151-155
R/G/B/W ring zoom in
156-160
Effect switch between R/G/B/W
161-165
Effect switch between Yellow/Purple/Cyan/white
166-255
Colour flowing in ring 1-4, 9 effects in total, each 10 digits for 1
effect
11
SMD ring Speed
000-255
Slow to fast
12
Auto program
000-049
No function
050-099
Auto program 1
100-149
Auto program 2
150-199
Auto program 3
200-249
Sound activated program
250-255
All Reset
23 Channels
Channel
Function
Value
Description
1
Pan
000-255
Pan 0-630°
2
Pan fine
000-255
Pan fine
3
Tilt
000-255
Tilt 0-210°
4
Tilt fine
000-255
Tilt fine
5
Speed
000-255
Pan/tilt speed
6
Dimming
000-255
Led dimming
7
Strobe
000-015
Strobe off
016-096
Strobe slow - Fast 1Hz to 25Hz
097-175
Strobe slow – Fast 1Hz
176-255
Random strobe
8
Colour Wheel
000-030
Open
031-055
Red
056-080
Green
081-105
Blue
106-130
Yellow
131-155
Orange
156-180
Magenta
181-205
Light green
206-230
Purple
231-255
Cyan
9
Gobo wheel
000-021
Open
022-034
Gobo 1
035-047
Gobo 2
048-060
Gobo 3
061-073
Gobo 4
074-086
Gobo 5
087-099
Gobo 6
100-112
Gobo 7
113-125
Gobo 8
126-138
Gobo 9
139-151
Gobo 1 Shake from slow to fast
152-164
Gobo 2 Shake from slow to fast
165-177
Gobo 3 Shake from slow to fast
178-190
Gobo 4 Shake from slow to fast
191-203
Gobo 5 Shake from slow to fast
204-216
Gobo 6 Shake from slow to fast
217-229
Gobo 7 Shake from slow to fast
230-242
Gobo 8 Shake from slow to fast
243-255
Gobo 9 Shake from slow to fast
10
SMD ring Red 1
000-255
Dimmer
11
SMD ring Green 1
000-255
Dimmer
12
SMD ring Blue 1
000-255
Dimmer
13
SMD ring Red 2
000-255
Dimmer
14
SMD ring Green 2
000-255
Dimmer
15
SMD ring Blue 2
000-255
Dimmer
